HKL/J0640412T Hi-BUS®KNX 640mA</br>power supply

HKL/J0640412T Hi-BUS®KNX 640mA
power supply

Provide stable operating voltage for BCU units. Bus current, bus voltage, and other communication signals can all be transmitted and fault diagnosed through the KNX bus. Voltage output overload and short circuit protection. The KNX power module is compatible with devices from other manufacturers, and the diagnostic and bus applications of the equipment can be shared with other standard devices. The KNX power module is connected to the KNX terminal device through a bus.

Product Features
Signal Transmission Fault Diagnosis Equipment Compatibility
  • Product Introduction
  • User Manual
  • Video


  • 001-KNX智能照明&智能家居-HKL-J0640412T KNX 640mA电源使用说明书V1.0.0.pdf
    down
